Expandrack
1 / 5
| RD-52# 200KG (40HQ Container Capacity: 425 Sets) | |
|---|---|
| Load Capacity | 200KG / Layer |
| Layers | Standard is 4 layers (can be custom made) |
| Colour Options | Gray white / Sand blue / Customizable |
| Specifications | Length: 2000 mm | Width: 600 mm | Height: 2000 mm |
| Key Features | Removable shelves reduce the packaging volume while maintaining the same load-bearing capacity, saving transportation costs and improving product competitiveness. |
| 40HQ Logistics Advantage | A 40HQ high container can accommodate 425 sets of 200kg shelves. With a carefully designed structure, it reduces packaging volume by 40% while maintaining equivalent load-bearing capacity. |
| Load / KG | Laminate Thickness | Column Specification | Crossbeam Specifications |
|---|---|---|---|
| 100 KG | 0.30 mm | 50 * 25 * 0.5 mm | 50 * 30 * 0.5 mm |
| 200 KG | 0.35 mm | 70 * 35 * 0.7 mm | 60 * 35 * 0.6 mm |
| 300 KG | 0.50 mm | 60 * 30 * 1.0 mm | 70 * 33 * 1.0 mm |
| 600 KG | 0.50 mm | 70 * 33 * 1.4 mm | 70 * 35 * 1.2 mm |
In order to provide you with a precise solution, please note the following guidelines:
